High Torque Low Speed 3000 rpm 2 Pole Industrial Electric DC Motors 30HP 22KW
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | high efficiency electric motors,waterproof electric motor |
||
|---|---|---|---|
High Torque Low Speed 3000 rpm 2 Pole Industrial Electric DC Motors 30HP 22KW
|
Ambient |
|
|
Temperature range: |
-15~40℃ |
|
Ambient humidity: |
90%less than relative humidity |
|
Altitude: |
less than 1000m above sea level |
|
Ambient condition: |
no causticity gas, no dust, no heavy mental pollution, no flame, no salt crystallization |
|
Supply power: |
|
|
Voltage variable |
±5% |
|
frequency variable |
±2% Combine voltage and frequency variable : ±5% |
|
Standard Feature: |
|
|
Standard |
IEC/GB |
|
Efficiency Level |
IE2 |
|
Phase |
Three-phase |
|
Frame Size |
H80~280 Cast iron frame |
|
Protect Feature |
Totally Enclosed |
|
Output Range |
0.75~90KW |
|
Voltage |
380V |
|
Frequency |
50HZ |
|
Pole |
2,4,6 |
|
Protection Class |
IP55 |
|
Insulation |
F/B |
|
Mounting |
IMB5/IM3001 |
|
Cooling |
IC411 |
|
Duty |
S1 |
|
Connection |
” Y" type for 3kW and downwards, "D" type for 4kW and upwards |
|
Thermometry |
Optional |
|
Certification |
CCC, CE,ISO9001 |
|
Special motors can be designed according to customers' requirements |
|
Greasing Period
|
Greasing Type |
Frame Size |
Poles |
Grease Life/Relubrication Interval(Up to CT40℃) |
|
Prelubricated |
H80~160 |
2 |
20000 h |
|
4,6 |
40000 h |
||
|
H180~280 |
2 |
20000 h |
|
|
4,6 |
40000 h |
Rated Power
|
Motor Type |
2 pole /3000 rpm |
4 pole /1500 rpm |
6pole /1000 rpm |
|||
|
kW |
HP |
kW |
HP |
kW |
HP |
|
|
YE2-80M1 |
0.75 |
1 |
|
|
|
|
|
YE2-80M2 |
1.1 |
1.5 |
0.75 |
1 |
|
|
|
YE2-90S |
1.5 |
2 |
1.1 |
1.5 |
0.75 |
1 |
|
YE2-90L |
2.2 |
3 |
1.5 |
2 |
1.1 |
1.5 |
|
YE2-100L |
3.0 |
4 |
2.2 |
3 |
1.5 |
2 |
|
|
|
3 |
4 |
|
|
|
|
YE2-112M |
4.0 |
5.5 |
4 |
5.5 |
2.2 |
3 |
|
YE2-132S1 |
5.5 |
7.5 |
5.5 |
7.5 |
3 |
4 |
|
YE2-132S2 |
7.5 |
10 |
|
|
|
|
|
YE2-132M |
|
|
7.5 |
10 |
4 |
5.5 |
|
|
|
|
|
5.5 |
7.5 |
|
|
YE2-160M1 |
11 |
15 |
11 |
15 |
7.5 |
10 |
|
YE2-160M2 |
15 |
20 |
|
|
|
|
|
YE2-160L |
18.5 |
25 |
15 |
20 |
11 |
15 |
|
YE2-180M |
22 |
30 |
18.5 |
25 |
|
|
|
YE2-180L |
|
|
22 |
30 |
15 |
20 |
|
YE200L |
30 |
40 |
30 |
40 |
18.5 |
25 |
|
37 |
50 |
|
|
22 |
30 |
|
|
YE225S |
|
|
37 |
50 |
|
|
|
YE225M |
45 |
60 |
45 |
60 |
30 |
40 |
|
YE250M |
55 |
75 |
55 |
75 |
37 |
50 |
|
YE280S |
75 |
100 |
75 |
100 |
45 |
60 |
|
YE280M |
90 |
125 |
90 |
125 |
55 |
75 |
Mounting Type:IMB5 /IM3001: without feet , but with flange on the DE side.
IM B5 Mounting and overall dimensions(mm)
|
Frame Size |
Pole |
Mounting Dimensions (mm) |
Overall Dimensions (mm) |
|||||||||||||
|
D |
E |
F |
G |
M |
N |
P |
S |
T |
R |
AC |
AD |
LD |
LA |
L |
||
|
80M |
2,4,6,8 |
19 |
40 |
6 |
15.5 |
165 |
130 |
200 |
4-￠12 |
3.5 |
0 |
167 |
165 |
74 |
12 |
300 |
|
90S |
2,4,6,8 |
24 |
50 |
8 |
20 |
165 |
130 |
200 |
4-￠12 |
3.5 |
0 |
190 |
175 |
76 |
12 |
350 |
|
90L |
2,4,6,8 |
24 |
50 |
8 |
20 |
165 |
130 |
200 |
4-￠12 |
3.5 |
0 |
190 |
175 |
76 |
12 |
385 |
|
100L |
2,4,6,8 |
28 |
60 |
8 |
24 |
215 |
180 |
250 |
4-￠14.5 |
4 |
0 |
215 |
200 |
83 |
13 |
435 |
|
112M |
2,4,6,8 |
28 |
60 |
8 |
24 |
215 |
180 |
250 |
4-￠14.5 |
4 |
0 |
240 |
220 |
87 |
14 |
470 |
|
132S |
2,4,6,8 |
38 |
80 |
10 |
33 |
265 |
230 |
300 |
4-￠14.5 |
4 |
0 |
275 |
240 |
102 |
14 |
510 |
|
132M |
2,4,6,8 |
38 |
80 |
10 |
33 |
265 |
230 |
300 |
4-￠14.5 |
4 |
0 |
275 |
240 |
102 |
14 |
560 |
|
160M |
2,4,6,8 |
42 |
110 |
12 |
37 |
300 |
250 |
350 |
4-￠18.5 |
5 |
0 |
320 |
285 |
149 |
15 |
670 |
|
160L |
2,4,6,8 |
42 |
110 |
12 |
37 |
300 |
250 |
350 |
4-￠18.5 |
5 |
0 |
320 |
285 |
149 |
15 |
700 |
|
180M |
2,4,6,8 |
48 |
110 |
14 |
42.5 |
300 |
250 |
350 |
4-￠18.5 |
5 |
0 |
380 |
310 |
161 |
15 |
740 |
|
180L |
2,4,6,8 |
48 |
110 |
14 |
42.5 |
300 |
250 |
350 |
4-￠18.5 |
5 |
0 |
380 |
310 |
161 |
15 |
780 |
|
200L |
2,4,6,8 |
55 |
110 |
16 |
49 |
350 |
300 |
400 |
4-￠18.5 |
5 |
0 |
410 |
335 |
186 |
17 |
780 |
|
225S |
4.8 |
60 |
140 |
18 |
53 |
400 |
350 |
450 |
4-￠18.5 |
5 |
0 |
470 |
370 |
189 |
20 |
820 |
|
225M |
2 |
55 |
110 |
16 |
49 |
400 |
350 |
450 |
4-￠18.5 |
5 |
0 |
470 |
370 |
189 |
20 |
815 |
|
4,6,8 |
60 |
140 |
18 |
53 |
400 |
350 |
450 |
4-￠18.5 |
5 |
0 |
470 |
370 |
189 |
20 |
845 |
|
|
250M |
2 |
60 |
140 |
18 |
53 |
500 |
450 |
550 |
4-￠18.5 |
5 |
0 |
490 |
380 |
207 |
22 |
915 |
|
4,6,8 |
65 |
140 |
18 |
58 |
500 |
450 |
550 |
4-￠18.5 |
5 |
0 |
490 |
380 |
207 |
22 |
915 |
|
|
280S |
2 |
65 |
140 |
18 |
58 |
500 |
450 |
550 |
4-￠18.5 |
5 |
0 |
580 |
410 |
215 |
22 |
985 |
|
4,6,8 |
75 |
140 |
20 |
67.5 |
500 |
450 |
550 |
4-￠18.5 |
5 |
0 |
580 |
410 |
215 |
22 |
985 |
|
|
280M |
2 |
65 |
140 |
18 |
58 |
500 |
450 |
550 |
4-￠18.5 |
5 |
0 |
580 |
410 |
215 |
22 |
1035 |
|
4,6,8 |
75 |
140 |
20 |
67.5 |
500 |
450 |
550 |
4-￠18.5 |
5 |
0 |
580 |
410 |
215 |
22 |
1035 |
|
Remark: R=Distance from flange to shaft shoulder.
Terminal Box
|
Frame Size |
Dia.of the thread(mm) |
X*Y*Z(mm) |
|
80 |
1-M24*1.5 |
95*95*50 |
|
90-100 |
1-M24*1.5 |
102*102*50 |
|
112-132 |
2-M30*2 |
108*123*75 |
|
160-180 |
2-M36*2 |
150*160*105 |
|
200-225 |
2-M48*2 |
188*208*105 |
|
250-280 |
2-M64*2 |
216*251*120 |
Description:
YE2 series high-efficiency three phase asynchronous motor is a development based on the YP2 series motor while considering the demand for energy conservation around the world. The mounting, bearings, terminal box, mounting dimensions are as the same as YP2 series. But its average efficiency is 2.55%higher than YP2 series motor.
According to IEC standard and Chinese energy-efficiency standard profoundly,this series reach the internationally general protection level(IP55)and insulation class (F insulation and B temperature rise).Boast several features such as high efficiency, high starting torque, low noise, more reliable structure and well appearance.
Adopt the cooling method of IC411 that is matured in the cooling and heat dissipation.
Our company has passed ISO9001 certification and followed its requirements from ordering, development, fabrication, inspection to sales service strictly.
The following as options or customer’s request:
Protection class IP56
Space heater
Heat protector
Vibration detector
Special mounting dimension and shaft dimension
Low vibration and low noise
Bearing thermometer PT100(frame size H180 and above)
Winding thermometer PT100
Special painting
Humid-tropical “TH”
Others
Applications:
They can be widely used for driving various common machines and equipments such as compressors,fans,water pumps, textile and crushers. Furthermore they can function as prime motor in relatively severe conditions including petroleum,chemical,pharmaceutical and mining industries.
Competitive Advantage:
HD motors stem from China with almost 20years manufacture history, which is a famous motor brand in China. Relying on continuous innovation, HD motors become one of the best in low votage motor production with their perfect performance , reliable quality , high efficiency and energy reservation.
High quality insulation material combines the perfect insulation system.
Perfect primer ensures the motors with good appearance and the motors are durable.
1. Focus on the manufacture of Low Voltage Motors;
2. Efficient customer services
3. Customized motors.
4. Competitive and reasonable pricing and delivery term;
5. Perfect quality assurance system
6. Credible after-sale service and warranty commitments
