High Torque High Temperature Electric Motors 3KW 4KW , Waterproof IP54 / IP55

High Torque 3KW 4KW High Temperature Electric Motors , Waterproof IP54 / IP55

IE2 standard YE2GW High temperature resistant three phase asynchronous motors in Industry (H132 Cast Iron Frame)

Technical Specification

Description:

With the development of textile printing and dyeing machinery, higher requirements are asked on motor working conditions and performance.  The working condition for circulating fan of dyeing machine is even worse.

YE2GW series motor is our second generation of high temperature resistant motor, designed on the basis in our company 20 years experience and according to user request.

The motor has aesthetic appearance and oil drain device for injection at DE and NDE side. Inner cover also has oil thrower inside to avoid grease into the lumen when oiling.

When the Ambient temperature is less than 55 degrees, the temperature of shaft , flange and other parts increase to 250 degrees, the motor can be still working well for connecting directly to the circulating fan.

Using high temperature resistant bearing which should be filled in 7017-1 high temperature grease after 1500 hours running.

H class insulation makes the motor with higher heat stability and longer life, and ensures the continuous production of printing and dyeing machinery industry.

Applications:

The motor application is directing for circulation fan, printing and dyeing machinery industry or other similar conditions..

Competitive Advantage:

HD motors stem from China with almost 20years manufacture history, which is a famous motor brand in China. Relying on continuous innovation,YE2GW High temperature resistant motors become one of the best in dyeing machinery industry with their perfect performance , reliable quality , high efficiency and energy reservation.

The motor is made of high quality cast iron .with optimized construction design, they can ensure the requirement of structure rigidity and intensity .

High quality insulation material combines the perfect insulation system.

We use high temperature resistant bearing to ensure the stable quality of the motor.

Perfect primer ensures the motors with good appearance and the motors are durable.
